ABB SYNCHROTACT 5302 电力系统同步装置

ABB SYNCHROTACT 5302 是一款高性能的电力系统同步装置，专为发电厂、变电站和工业电力系统设计。

它能够实现发电机与电网的同步并网操作，确保电力系统的稳定运行。

存储温度：-40°C 至 +85°C。

死母线检测：支持死母线条件检测，确保在母线无电压时的安全操作。

工业电力系统：用于工业过程中的电力设备同步。

ABB SYNC HROTACT 5302 Power System Synchronization Device

product overview

ABB SYNC HROTACT 5302 is a high-performance power system synchronization device designed specifically for power plants, substations, and industrial power systems.

It can achieve synchronous grid connection operation between the generator and the power grid, ensuring the stable operation of the power system.

technical specifications

Auxiliary voltage:

Rated voltage range: 24-250 VDC, 100-230 VAC.

Allowable voltage range: 18-300 VDC, 75-300 VAC.

Measurement input:

Rated voltage range: 50-130 VAC.

Frequency range: 10-100 Hz.

Digital input:

Rated voltage: 24/48 VDC.

Current consumption: 6-8 mA.

Parallel relay:

Maximum contact voltage: 250 VAC/VDC.

Maximum switching power (on/off): 1500 VA/W (resistive).

Adjust command and signal relays:

Maximum contact voltage: 250 VAC/VDC.

Maximum switching power: 50 VA/W.

Communication interface:

Supports protocols such as Modbus RTU, Profibus, Lon, etc.

Ethernet interface, supporting remote services.

power waste:

Maximum power consumption (ready state): 25 W/35 VA.

Size and weight:

Size: 443 mm x 155 mm (panel opening size).

Weight: 8 kg.

Protection level:

Front panel: IP54.

Rear panel: IP50.

Working temperature range:

Operating temperature: -40 ° C to+70 ° C.

Storage temperature: -40 ° C to+85 ° C.

Functional Features

High precision synchronization: Provides high-precision voltage, frequency, and phase angle measurements to ensure the accuracy of synchronization operations.

Redundancy design: Supports dual channel redundancy to improve system reliability and availability.

Multiple communication protocols: Supports multiple industrial communication protocols for easy integration with other control systems.

Remote service: Supports remote service through Ethernet interface to reduce maintenance costs.

User friendly interface: equipped with PC tool "SynView", supporting parameter settings, actual value display, transient recording, and event logging.

Multiple synchronization conditions: Supports multiple synchronization condition settings, including slip limit, angle limit, and voltage difference limit.

Dead bus detection: supports dead bus condition detection to ensure safe operation when there is no voltage on the bus.

application area

Power plant: used for synchronous grid connection operation between generators and the power grid.

Substation: Implement synchronous control of equipment within the substation.

Industrial power system: used for synchronizing power equipment in industrial processes.
