ABB PNI800 通信接口模块是一款专为PN800系统设计的高性能通信接口设备。以下是关于该模块的主要特点和详细信息：

主要特点

1. 适用范围：
• 适用于需要连接到PN800的电脑和自动化控制系统。
• 每个HMI服务器需要1个PNI800，包括S+操作服务器和800xA PPA的Harmony RTDS。
• 1个PNI800最多可由10个Composer客户端工作站共享。
2. 设计特性：
• 用户友好、直观且符合人体工程学的操作面板，方便用户进行操作。
• 纤薄、节省空间的尺寸设计，同时结合全面的高级功能。
• Panel 800 6.2版系列由标准、黑色和坚固的面板组成，具有更多的接口选项、速度和显示屏功能。
3. 通信能力：
• 支持多种通信协议和接口，如EtherNet/IP、Modbus等，方便与其他设备或控制系统进行数据交换和通信。
• 连通性强，可连接到两条以太网线路，并支持PN800线路冗余。
• 支持RS232、RS422、RS485等串口通信方式，以及无线电台、电话拨号、电话轮询拨号等多种通信方式。
• 有线和无线以太网通信支持，同时驱动程序支持GPRS、CDMA、GSM等移动网络标准。
4. 规格参数：
• 电源要求：每个处理器模块大约3.5W@+24 VDC。
• 通信总线：4.0 Mbps RS485，最大长度电气50米，光纤3.0公里。
• PROFIBUS：支持多种波特率，最大总线长度从100米到1200米不等。
5. 容量与连接：
• 最多8个PDP800可以连接到HPC800。
• 每个PDP800最多支持64个从设备。
6. 开发环境：
• 提供方便的开发环境，包括强大的HMI开发系统，灵活的矢量子图，以及支持面向对象编程方式等。

ABB PNI800 communication interface module is a high-performance communication interface device designed for PN800 systems. Here are the main features and details of the module:

Main feature

Scope of application:

Suitable for computers and automation control systems that need to be connected to the PN800.

Each HMI server requires 1 PNI800, including the S+ operating server and Harmony RTDS with 800xA PPA.

One PNI800 can be shared by up to 10 Composer client workstations.

Design features:

User-friendly, intuitive and ergonomic operation panel for easy operation.

Slim, space-saving dimensions combined with a full range of advanced features.

The Panel 800 Version 6.2 series consists of standard, black and rugged panels with more interface options, speed and display capabilities.

Communication capability:

Support a variety of communication protocols and interfaces, such as EtherNet/IP, Modbus, etc., to facilitate data exchange and communication with other devices or control systems.

Strong connectivity to two Ethernet lines and support for PN800 line redundancy.

Support RS232, RS422, RS485 and other serial communication methods, as well as radio, telephone dialing, telephone polling dialing and other communication methods.

Wired and wireless Ethernet communication support, while the driver supports GPRS, CDMA, GSM and other mobile network standards.

Specification parameters:

Power requirements: Approximately 3.5W@+ 24VDC per processor module.

Communication bus: 4.0Mbps RS485, the maximum length of electrical 50 meters, optical fiber 3.0 kilometers.

PROFIBUS: Supports a variety of baud rates, with maximum bus lengths ranging from 100 meters to 1200 meters.

Capacity and connectivity:

Up to 8 PDP800s can be connected to the HPC800.

Each PDP800 supports up to 64 slave devices.

Development environment:

Provide convenient development environment, including powerful HMI development system, flexible vector subgraph, and support object-oriented programming.
