Basic Product Information

Project Content

Brand General Electric (GE)

Model IS220PPROH1A

Type Input/Output (I/O) Module

Series Mark VI (IS220PPRO)

Revised version REV: D (provided by some suppliers)

Origin: United States

core functionality

1. Main functions

Signal processing: supports digital input (DI), digital output (DO), analog input (AI), and analog output (AO)

Direct device interface: provides a direct interface for specific turbine field equipment, reducing instrument usage

Emergency trip support: often used in conjunction with TREAH_S terminal board for emergency trip applications of aircraft modified turbines

Communication: Communicate with the controller through IONet network

2. Hardware characteristics

Characteristic description

Processor PowerPC 604e, 333MHz

Two independent 10/100 Ethernet ports for communication

High speed processing capability with built-in high-speed processor and watchdog timer

AE bridge interface supports right angle connectors, seven pin vertical connectors, and three hole plugs

LED indicator lights for status indication such as PWR/ATTN, LINK/TxRx, ENET1, ENET2, etc

3. Speed signal support

Accept three speed signals: deceleration, acceleration, and overspeed

Equipped with hardware overspeed function

Support TMR and simplex backup protection

technical parameters

Source of parameter specifications

Input voltage 24V DC/27.4-28.6VDC

Output voltage 5V DC/0-10V

Working temperature -40 ℃ -+85 ℃/0-55 ℃

Size 100mm × 50mm × 30mm/VME standard

Weight approximately 0.75 pounds/1 kilogram/200g

Power consumption is about 50W/10W

Humidity requirement<85% (no condensation)

Cable limit 1000 feet 18 AWG

application field

Specific Application Fields and Uses

Gas/Steam Turbine Control Mark VI Speedtronic System

Gas and steam turbine power plants in the power generation industry

Ship propulsion industrial steam turbine control system

Oil and gas industry control and process monitoring

Dangerous areas are suitable for both hazardous and non hazardous locations (with the assistance of an ID board)

System configuration and compatibility

Redundant configuration: suitable for non redundant, dual redundant, and triple redundant systems

Matching terminal board: usually used in conjunction with TREAH_S terminal board

ID board accessories: need to be used in conjunction with the IS200SPIDG1A accessory ID board

Change restriction: When swapping BPPB P-Pack with BPPC P-Pack, automatic reconfiguration is not possible

Authentication and Security

Certification Type Certification Number/Level

UL certification UL E207685

Class I Division 2，Groups A、B、C、D

Class I Zone 2，Group IIC

ATEX certification UL DEMKO 12 ATEX 1114875X

Precautions

Model differentiation: IS220PPRFH1A is the main gateway module for GE Mark VI series PROFIBUS, and is not the same product as IS220PPROH1A

Electrical specifications: Electrical specifications must be followed during use to eliminate potential risks of property damage or personal injury

Warranty service: Usually provides a 12-month warranty

Supply information: Some suppliers offer in stock, with a delivery time of approximately 5-8 working days
