美国GE电气的VMIVME-4150紧急保护端子板是一款高性能、高可靠性的产品，专为各种工业自动化和控制系统应用而设计。以下是对该产品的详细介绍、说明、特点以及应用行业的概述：

产品介绍与说明

VMIVME-4150紧急保护端子板是一款12位模拟输出板，提供12个隔离的高质量模拟输出通道。每个通道都与其他通道以及VME总线完全隔离，这有助于保护系统免受电气干扰和故障的影响。此外，它还提供了多种配置选项，以满足不同应用的需求。

特点

1. 高隔离性：每个通道都与其他通道和VME总线完全隔离，提供高达1000 Vpk的隔离电压，确保系统的稳定性和安全性。
2. 高分辨率：提供12位分辨率的模拟输出，可实现精确的控制和测量。
3. 灵活的电压输出范围：双极性电压输出范围可选择为2.5、5或10V，单极性电压输出范围可选择为0至2.5V、0至5V或0至10V。
4. 强大的负载能力：在整个10 V范围内，电压输出的负载能力为10mA，同时提供4至20、0至20或5至25mA的电流输出。
5. 高精度输出：环路输出电压输出精度为0.05%，电流环路输出精度为0.08%。
6. 易于配置和控制：提供4至8或12通道配置选项，支持光学数据耦合以实现完全的电流隔离。此外，还提供静态回读数据寄存器，简化程序控制，并具备前面板入口电压输出的程控连接/断开操作功能，有助于系统试验。

应用行业

VMIVME-4150紧急保护端子板因其高隔离性、高分辨率和灵活的电压输出范围等特点，广泛应用于多个行业，包括但不限于：

1. 工业自动化：用于实现各种自动化控制任务，如设备监控、生产线控制等。其高隔离性和精确的模拟输出使其成为工业自动化领域的理想选择。
2. 能源管理：在风力发电、太阳能发电等新能源领域，VMIVME-4150可用于实现精确的能源监测和控制。
3. 交通运输：用于铁路、航空、港口等交通领域的自动化控制系统，确保交通运输的安全和高效。
4. 医疗设备：在医疗领域，VMIVME-4150可用于医疗影像处理、医疗仪器控制等，为医疗领域提供精确、可靠的技术支持。

总之，美国GE电气的VMIVME-4150紧急保护端子板是一款高性能、高可靠性的产品，具有多种配置选项和灵活的应用范围，广泛适用于工业自动化、能源管理、交通运输和医疗设备等领域。

The VMIVME-4150 emergency protection terminal board from GE Electric is a high-performance and highly reliable product designed specifically for various industrial automation and control system applications. The following is a detailed introduction, description, characteristics, and overview of the application industry of this product:

Product Introduction and Description

The VMIVME-4150 emergency protection terminal board is a 12 bit analog output board that provides 12 isolated high-quality analog output channels. Each channel is completely isolated from other channels and the VME bus, which helps protect the system from electrical interference and faults. In addition, it also provides multiple configuration options to meet the needs of different applications.

characteristic

High isolation: Each channel is completely isolated from other channels and VME bus, providing isolation voltage of up to 1000 Vpk to ensure system stability and safety.

High resolution: Provides 12 bit resolution analog output for precise control and measurement.

Flexible voltage output range: The bipolar voltage output range can be selected as 2.5, 5, or 10V, and the unipolar voltage output range can be selected as 0 to 2.5V, 0 to 5V, or 0 to 10V.

Powerful load capacity: Within the entire 10 V range, the voltage output has a load capacity of 10 mA, while providing a current output of 4 to 20, 0 to 20, or 5 to 25 mA.

High precision output: The voltage output accuracy of the loop is 0.05%, and the current loop output accuracy is 0.08%.

Easy to configure and control: Provides 4 to 8 or 12 channel configuration options, supporting optical data coupling for complete current isolation. In addition, it also provides static read back data registers to simplify program control, and has a programmable connection/disconnection operation function for front panel input voltage output, which is helpful for system testing.

Application industry

The VMIVME-4150 emergency protection terminal board is widely used in multiple industries due to its high isolation, high resolution, and flexible voltage output range, including but not limited to:

Industrial automation: used to achieve various automation control tasks, such as equipment monitoring, production line control, etc. Its high isolation and precise analog output make it an ideal choice in the field of industrial automation.

Energy management: In the field of new energy such as wind power and solar power, VMIVME-4150 can be used to achieve precise energy monitoring and control.

Transportation: an automated control system used in transportation fields such as railways, aviation, and ports to ensure the safety and efficiency of transportation.

Medical equipment: In the medical field, VMIVME-4150 can be used for medical image processing, medical instrument control, etc., providing precise and reliable technical support for the medical field.

In summary, GE Electric's VMIVME-4150 emergency protection terminal board is a high-performance and highly reliable product with multiple configuration options and flexible application ranges, widely used in industrial automation, energy management, transportation, and medical equipment fields.
