GE通用电气IS200VSVOH1B伺服控制器是一款专为涡轮机控制设计的电路板组件,作为Mark VI系列的一部分,具有多项关键特性和技术规格。以下是关于IS200VSVOH1B伺服控制器的详细介绍:
GE GE IS200VSVOH1B Servo controller is a circuit board component designed for turbine control as part of the Mark VI series with several key features and technical specifications. The following is a detailed introduction to the IS200VSVOH1B servo controller:
Product Overview:
The IS200VSVOH1B is a circuit board assembly manufactured by General Electric (GE) for Mark VI for use in gas/steam turbine management systems.
The Mark VI series is part of GE's long-running and popular Speedtronic gas turbine management series, which began in the 1960s.
Functional features:
Ethernet communication function: provides high-speed and reliable data transmission.
Pc-based operator interface: Easy user intuitive operation and monitoring.
Integrated hardware and software designed for turbine control: ensure system stability and efficiency.
Application and operation:
Used as a servo control board to drive the fuel/steam valve by controlling four electro-hydraulic servo valves.
Provides pulse velocity flow input, LVDT excitation, and LVDT position feedback for precise control.
It can be used in triple redundant systems and simplex systems to ensure system reliability and flexibility.
Design and Structure:
There is a single slot front panel connected to the PCB that includes cable connectors (J5) and LED indicators for status information.
The LED indicators on the front panel include RUN (green), fault (red), and status indicators (usually not powered on, but displayed as steady orange under alarm conditions).
There are six connectors, including two backplanes (P1/P2) and four connectors made of conductive wires (P3 to P6).
Four relays (K1 to K4) are included, with a printed diagram on the top surface of each component.
Equipped with resistors, capacitors, TP test points and inductive magnetic beads (L1-L10).
More than 70 integrated circuits ensure high performance and reliability.
System characteristics:
The main processor and I/O card are fully triplicated to avoid system shutdown due to a single point of failure.
The optical isolation on the I/O card is all triples to improve system safety and stability.
All simulated cards (AI, AO, PI) have a high degree and can be automatically checked periodically to ensure the accuracy of data.
The system is TUV AK6 certified and meets the requirements of SIL Level 3, demonstrating its high reliability and safety.
The 32-bit chip ensures the fast operation of the system and improves the processing speed and response ability.
High system diagnostic coverage, diagnostic functions are built into the system, no need to write applications, simplifying maintenance and troubleshooting processes.
