HONEYWELL LG1093AC01 紫外线火焰传感器 是霍尼韦尔公司推出的一款专为工业应用设计的高性能火焰检测设备，

一、产品特性

1. 高灵敏度与快速响应：
   • LG1093AC01 能够迅速准确地检测火焰的存在，响应时间约为0.2秒，确保在火焰出现的瞬间即可发出信号。
2. 抗干扰能力强：
   • 该传感器有效抑制环境光和其他干扰源的影响，确保检测的准确性。即使在复杂多变的工业环境中，也能稳定可靠地工作。
3. 耐恶劣环境：
   • LG1093AC01 设计用于工业环境，具有良好的耐高温、耐振动和抗干扰性能。其工作温度范围广泛，适用于-40℃至+85℃的环境温度，满足各种极端工业条件的需求。
4. 长传输距离：

   • 传感器与放大器之间的最大传输距离可达330米，便于在大型工业设备中进行灵活布局和安装。

   •

二、技术参数

1. 检测波段：180-260纳米，这一波段是火焰产生的紫外线辐射的主要范围，确保传感器能够准确捕捉火焰信号。
2. 工作电压：支持28VDC、20-35VDC或115VAC等多种电压输入，适应不同工业设备的电源需求。
3. 环境温度：-40℃至+85℃，宽温度范围设计，确保传感器在各种极端环境下都能正常工作。

三、应用领域

LG1093AC01 紫外线火焰传感器广泛应用于需要火焰监测的工业设备中，如：

1. 燃气轮机：在燃气轮机的燃烧过程中，实时监测火焰状态，确保燃烧稳定和安全。
2. 工业炉窑：在工业炉窑的加热过程中，通过检测火焰来控制加热温度和时间，提高生产效率和产品质量。
3. 锅炉：在锅炉的燃烧过程中，监测火焰状态以防止熄火或爆炸等安全事故的发生。

HONEYWELL LG1093AC01 UV flame sensor is a high-performance flame detection device designed specifically for industrial applications by Honeywell,

1、 Product Features

High sensitivity and fast response:

LG1093AC01 can quickly and accurately detect the presence of flames, with a response time of about 0.2 seconds, ensuring that a signal can be emitted at the moment the flame appears.

Strong anti-interference ability:

This sensor effectively suppresses the influence of ambient light and other interference sources, ensuring the accuracy of detection. Even in complex and ever-changing industrial environments, it can work stably and reliably.

Resistant to harsh environments:

LG1093AC01 is designed for industrial environments and has excellent high temperature resistance, vibration resistance, and anti-interference performance. Its working temperature range is wide, suitable for ambient temperatures ranging from -40 ℃ to+85 ℃, meeting the needs of various extreme industrial conditions.

Long transmission distance:

The maximum transmission distance between sensors and amplifiers can reach 330 meters, making it easy to flexibly layout and install in large industrial equipment.

2、 Technical parameters

Detection band: 180-260 nanometers, which is the main range of ultraviolet radiation generated by flames, ensuring that the sensor can accurately capture flame signals.

Working voltage: Supports multiple voltage inputs such as 28VDC, 20-35VDC, or 115VAC to meet the power requirements of different industrial equipment.

Environmental temperature: -40 ℃ to+85 ℃, designed with a wide temperature range to ensure that the sensor can function properly in various extreme environments.

3、 Application Fields

The LG1093AC01 ultraviolet flame sensor is widely used in industrial equipment that requires flame monitoring, such as:

Gas turbine: During the combustion process of the gas turbine, real-time monitoring of the flame state is carried out to ensure stable and safe combustion.

Industrial furnaces: In the heating process of industrial furnaces, the heating temperature and time are controlled by detecting the flame to improve production efficiency and product quality.

Boiler: During the combustion process of the boiler, monitor the flame state to prevent safety accidents such as flameout or explosion.
