WOODWARD 2301E 8273-1011 控制模块

产品概述

WOODWARD 2301E 8273-1011 是一款基于微处理器的数字控制模块，专为工业自动化和发动机控制系统设计。它能够实现对柴油或气体发动机驱动的发电机的负载分配和速度控制。

技术规格

输入电压：24V DC（工作范围 18-36V DC）。

输出电压：4-20 mA DC 或 0-10 V DC。

工作温度范围：-40°C 至 +85°C。

尺寸：96 x 48 x 100 mm 或 150 mm × 100 mm × 50 mm。

重量：约 0.15 kg 或 100g。

安装方式：DIN 导轨安装。

通信接口：RS-232、RS-422 和 RS-485。

控制功能：

1 个负载传感器电路。

1 个执行器驱动器（支持 4-20 mA、0-20 mA、0-200 mA 或 PWM 输出）。

1 个 MPU 速度传感器。

1 个可配置模拟输出。

2 个可配置模拟输入。

8 个离散（开关）输入（3 个可配置）。

4 个离散（继电器驱动器）输出（1 个固定，3 个可配置）。

功能特点

高精度控制：提供精确的速度和负载控制，速度控制精度可达 ±0.25%。

灵活性：可通过程序进行配置和调整，适应不同的应用场景。

可靠性：设计紧凑且耐用，适用于多种工业环境。

多功能性：兼容广泛的工业设备和系统。

故障检测与保护：具备故障检测功能，可监测系统和传感器的状态，并在出现问题时触发警报。

数据记录与通信：支持多种通信协议（如 Modbus、Ethernet 等），便于与其他系统和设备集成。

应用领域

发电机组控制：用于柴油或气体发动机驱动的发电机的负载分配和速度控制。

燃气轮机控制：在燃气轮机控制系统中，实现精确的转速和负载控制。

水轮机控制：用于混流式水轮机等设备的转速和负载控制。

工业自动化：在工业自动化领域，作为核心控制模块，实现设备的自动化运行。

其他应用：适用于需要调速控制的电机驱动应用，如风机、泵、压缩机等。

Woodward 2301e 8273-1011 control module

Product overview

Woodward 2301e 8273-1011 is a microprocessor-based digital control module designed for industrial automation and engine control systems. It can realize the load distribution and speed control of diesel or gas engine driven generators.

technical specifications

Input voltage: 24V DC (working range: 18-36V DC).

Output voltage: 4-20 mA DC or 0-10 V DC.

Operating temperature range: -40 ° C to+85 ° C.

Dimensions: 96 X 48 x 100 mm or 150 mm x 100 mm x 50 mm.

Weight: about 0.15 kg or 100g.

Installation method: DIN rail installation.

Communication interface: RS-232, RS-422 and RS-485.

Control function:

1 load sensor circuit.

1 actuator driver (supports 4-20 mA, 0-20 Ma, 0-200 Ma or PWM output).

1 MPU speed sensor.

1 configurable analog output.

2 configurable analog inputs.

8 discrete (switch) inputs (3 configurable).

4 discrete (relay driver) outputs (1 fixed, 3 configurable).

Functional features

High precision control: provide accurate speed and load control, and the speed control accuracy can reach ± 0.25%.

Flexibility: it can be configured and adjusted through the program to adapt to different application scenarios.

Reliability: compact and durable design, suitable for a variety of industrial environments.

Versatility: compatible with a wide range of industrial equipment and systems.

Fault detection and protection: with fault detection function, it can monitor the status of the system and sensors, and trigger an alarm in case of problems.

Data recording and communication: support a variety of communication protocols (such as modbus, Ethernet, etc.) to facilitate integration with other systems and equipment.

application area

Generator set control: used for load distribution and speed control of diesel or gas engine driven generators.

Gas turbine control: in the gas turbine control system, accurate speed and load control is realized.

Turbine control: used for speed and load control of Francis turbine and other equipment.

Industrial automation: in the field of industrial automation, as the core control module, it realizes the automatic operation of equipment.

Other applications: suitable for motor drive applications requiring speed control, such as fans, pumps, compressors, etc.

If you need to further understand or purchase Woodward 2301e 8273-1011 control module, it is recommended to contact the relevant supplier
