Woodward 8440-1706 是一款高性能的数字调速器模块，广泛应用于工业自动化和发电系统控制。

产品概述

Woodward 8440-1706 是一款专为工业自动化和发电系统设计的数字调速器模块。它集成了多种先进功能，能够满足复杂电力系统的需求，提供高效且稳定的运行。

主要功能与特点

多功能集成：集成了同步器、负载传感器、负载控制、死母线闭合系统、无功功率、功率因数和过程控制功能。

支持多台发电机并联：可支持多达 32 台发电机的精确并联和控制，确保负载平衡。

通信功能：提供专用以太网系统，支持 Modbus-TCP 协议，便于与 DCS 和 PLC 系统集成。

控制与保护：支持多种控制模式（如速度控制、扭矩控制等），并内置过压、过流、过热等保护功能。

灵活性与可配置性：支持多种输入电压（如 24V DC）和频率范围（50/60Hz），适用于不同应用场景。

环境适应性：工业级设计，工作温度范围为 -25℃ 至 70℃，防护等级为 IP20。

技术规格

尺寸：144mm × 72mm × 122mm。

重量：约 0.8kg。

测量范围：电压、电流、频率、功率。

精度：±0.5%，分辨率 0.1。

通道数量：16。

应用场景

该模块广泛应用于以下行业：

石油和天然气

电力生成

制造业

船舶

其他信息

输入电压：通常为 24V DC，输入电压范围在 20V DC 至 30V DC 之间。

输出电流：标准输出电流为 5A，某些应用中可能达到 100-400A。

工作温度：操作温度范围从 -40℃ 至 85℃。

Woodward 8440-1706 is a high-performance digital speed controller module widely used in industrial automation and power generation system control.

product overview

Woodward 8440-1706 is a digital governor module designed specifically for industrial automation and power generation systems. It integrates multiple advanced functions to meet the needs of complex power systems, providing efficient and stable operation.

Main functions and features

Multi functional integration: integrates synchronizers, load sensors, load control, dead bus closure system, reactive power, power factor, and process control functions.

Supporting parallel connection of multiple generators: It can support precise parallel connection and control of up to 32 generators to ensure load balancing.

Communication function: Provides a dedicated Ethernet system that supports Modbus TCP protocol for easy integration with DCS and PLC systems.

Control and Protection: Supports multiple control modes (such as speed control, torque control, etc.), and has built-in protection functions for overvoltage, overcurrent, overheating, etc.

Flexibility and Configurability: Supports multiple input voltages (such as 24V DC) and frequency ranges (50/60Hz), suitable for different application scenarios.

Environmental adaptability: Industrial grade design, working temperature range of -25 ℃ to 70 ℃, protection level of IP20.

technical specifications

Dimensions: 144mm × 72mm × 122mm.

Weight: Approximately 0.8kg.

Measurement range: voltage, current, frequency, power.

Accuracy: ± 0.5%, resolution 0.1.

Number of channels: 16.

Application scenarios

This module is widely used in the following industries:

Oil and Gas

Electricity generation

manufacturing

ship

Other information

Input voltage: usually 24V DC, with an input voltage range between 20V DC and 30V DC.

Output current: The standard output current is 5A, and in some applications it may reach 100-400A.

Working temperature: The operating temperature range is from -40 ℃ to 85 ℃.
