产品介绍

产品参数:1764-24BWA MicroLogix 1500可编程逻辑数字控制器(PLC)

Allen-Bradley 1764-245WA是MicroLogix 1500可编程逻辑控制器(PLC)的一部分。该部件号是容纳必要的MicroLogix 1500模块(如处理器和内存模块)的基本单元。当与1764处理器—起安装时，基本单元成为功能PLC。

1764-24BWA是一个可独立更换的装置，允许最大化嵌入式/O选项，同时最小化库存成本。它包含电源、通信端口以及嵌入式输入和输出。公告1764-24BWA基本单元允许通过其通道0端口与其他设备进行高级通信。它充当应用程序所需的扩展I/O接口。它带有八个标准和四个快速24伏DC输入和四个20千赫高速输入。1764-24BWA基础需要处理器才能工作，它与1764-LRP或1764-LSP兼容。

它有一条120到240伏的交流额定电源线和12个继电器(其中两个是隔离的)。它的功耗为88 VA，最大负载功率为22，电源电压为85至265伏交流电，频率为47至63赫兹。它还有一个24伏DC功率传感器，额定最大电容为400毫安或400华氏度，这是其他基本单元所不具备的强大功能。1764-24BWA底座拥有CE、C-Tick、UL、 c-UL和级2区危险场所操作的产品认证。它与Bulletin 1764处理器一起构成完整的控制器。这种组件不应该安装在电力线附近。

Allen-Bradley 1764L.24BWA是MicroLogix 1500基本单元。该基本单元提供了模块化外壳。此基本单元可安装MicroLogix处理器，如1764-LSP和1764-IRP。此外，此基本单元可以安装数据访问工具(DAT ).如1764-DAT。安装到基本单元的其他兼容模块是内存模块和实时时钟。

1764-24BWA MicroLogix 1500基本装置具有集成的八(8个24VDC离散输入、四(4)个高速输入和十二(12)个继电器输出。该基本装置在安装过程中需要最小的面板空间。它可以使用DIN导轨或安装螺钉进行安装。控制器各侧的建议安装间隙为两(2)英寸。这是为了确保足够的通风。

1764-24BWA支持安装扩展模块，以增强基本单元的集成功能。兼容的扩展模块是1769紧凑型I/O模块。这些模块可以作为本地/O模块直接安装。此外，该基本单元还通过扩展机架支持扩展配置。这是通过使用1769扩展电缆实现的。

集成通信端口支持全双工或半双工DF1协议接口。它可与高级接口转换器(AIC) are 1761-NET-AIC、1761-NET-ENI接口，或通过使用DeviceNet扫描仪模块1769-SDN与DeviceNet网络接口。该转换器也可用于复用基本单元上的串行端口，从而允许人机界面(HMI)、监控和数据采集(SCADA).编程工作站、设备转换器和网关同时通信。

●所有产品图片均为真实人物，如果您需要更多照片，请联系我们。

●所有售出的产品质量保证一年，如果有质量问题我们可以给您更换或退回。

●我们是中国最大的工控产品供应商，如果您需要其他类型的产品，请向我们咨询，我们会立即给您答复。

o如果您购买的不止一个，我们会给您折扣，如果您收到价格，请与我们联系，我们将尽力让您满意，我们的客户来自世界各地，欢迎来到中国。

Product introduction

Product parameters :1764-24BWA MicroLogix 1500 Programmable Logic Digital Controller (PLC)

The Allen-Bradley 1764-245WA is part of the MicroLogix 1500 Programmable Logic Controller (PLC). This part number is the basic unit that houses the necessary MicroLogix 1500 modules, such as the processor and memory modules. When installed with a 1764 processor, the base unit becomes a functional PLC.

The 1764-24BWA is an independently replaceable unit that allows to maximize embedded /O options while minimizing inventory costs. It contains a power supply, communication ports, and embedded inputs and outputs. Bulletin 1764-24BWA Base unit allows advanced communication with other devices through its channel 0 port. It acts as the extended I/O interface required by the application. It comes with eight standard and four fast 24 volt DC inputs and four 20 KHZ high-speed inputs. The 1764-24BWA base requires a processor to work and is compatible with 1764-LRP or 1764-LSP.

It has a 120 to 240 volt AC rated power cord and 12 relays (two of which are isolated). It has a power consumption of 88 VA, a maximum load power of 22, a supply voltage of 85 to 265 volts AC, and a frequency of 47 to 63 Hertz. It also has a 24-volt DC power sensor rated for a maximum capacitance of 400 MA or 400 degrees Fahrenheit, a powerful feature not found in other base units. The 1764-24BWA base is certified for CE, C-Tick, UL, c-UL and Class 2 Hazardous Site operation. Together with the Bulletin 1764 processor, it forms a complete controller. Such components should not be installed near power lines.

Allen-Bradley 1764L.24BWA is the MicroLogix 1500 base unit. The basic unit is provided with a modular housing. This base unit can be installed with MicroLogix processors such as 1764-LSP and 1764-IRP. In addition, this base unit can install data access tools (DAT). Such as 1764-DAT. Other compatible modules installed to the base unit are the memory module and the real-time clock.

The 1764-24BWA MicroLogix 1500 base unit has integrated eight (8) 24VDC discrete inputs, four (4) high-speed inputs, and twelve (12) relay outputs. This basic unit requires minimal panel space during installation. It can be mounted using DIN rails or mounting screws. The recommended installation clearance on each side of the controller is two (2) inches. This is to ensure adequate ventilation.

1764-24BWA supports the installation of expansion modules to enhance the integration of the base unit. The compatible expansion module is the 1769 compact I/O module. These modules can be installed directly as local /O modules. In addition, the base unit supports extended configurations through extension racks. This is achieved by using the 1769 extension cable.

The integrated communication port supports full-duplex or half-duplex DF1 protocol interfaces. It can interface with the Advanced Interface Converter (AIC) are 1761-NET-AIC, 1761-NET-ENI, or with the DeviceNet network by using the DeviceNet scanner module 1769-SDN. The converter can also be used to reuse serial ports on the base unit, allowing for human machine interface (HMI), monitoring and data acquisition (SCADA). Programming workstations, device converters, and gateways communicate simultaneously.

● All product images are real people, if you need more photos, please contact us.

● The quality of all sold products is guaranteed for one year, if there is a quality problem, we can give you a replacement or return.

● We are the largest supplier of industrial control products in China, if you need other types of products, please contact us, we will reply to you immediately.

o If you buy more than one, we will give you a discount, if you receive the price, please contact us, we will try our best to make you satisfied, our customers come from all over the world, welcome to China.
