### ABB 3BHE004573R0145 UFC760BE145 输入输出控制卡

#### 技术规格

- **型号**：3BHE004573R0145

- **备用型号**：UFC760BE145

- **制造商**：ABB

- **系列**：UNITOL 6000

- **产品类型**：相位调制器

- **功能**：直流母线电路的链接保护、内置制动电路、故障诊断和保护机制。

- **额定电压**：3.3kV – 6.6kV (50/60Hz)

- **工作电压**：230V AC。

- **输出频率**：50Hz。

- **输入电流**：2.0A。

- **控制精度**：±0.1%。

- **通信协议**：MODBUS TCP/IP, PROFIBUS DP, Modbus TCP, IEC 61850。

- **控制更新时间**：250μs。

- **功耗**：24W @ 24V DC ±15%。

- **工作温度范围**：-25°C至+55°C。

- **尺寸**：482.6 x 132.5 x 405 mm (19″ rack)。

- **重量**：0.5kg。

- **防护等级**：IP20（前面板），IP00（内部）。

- **认证**：UL 508C, CE, cULus。

#### 应用领域

- **电力系统**：用于高压变频器和逆变器，提高传输效率和电力质量。

- **工业自动化**：适用于冶金、矿业和水泥行业的高功率设备的变频控制。

- **轨道交通**：支持牵引系统的稳定运行，确保高压辅助供电系统的可靠性。

- **新能源领域**：适用于风能和光伏系统，优化电力输出。

#### 特点

- **高精度控制**：采用先进的控制算法，实现±0.1%的速度调节精度。

- **广泛的适应性**：支持多种电压级别，适用于高压变频器、逆变器、风能和光伏系统。

- **高效电力管理**：通过优化相位控制和电力质量，提高系统效率，减少能源损失。

- **增强的连接性**：支持多种通信协议和接口类型，便于与其他设备集成。

- **创新的热设计**：采用氮化铝陶瓷基板，可在高达85°C的环境温度下处理150A的连续电流。

#### 注意事项

- **安装环境**：确保模块安装在无尘、干燥且通风良好的环境中，避免高温、高湿或腐蚀性气体。

- **电气连接**：正确连接电源和信号线，避免接线错误导致的模块损坏或性能下降。

ABB 3BHE004573R0145 UFC760BE145 是一款高性能的相位调制器，广泛应用于工业自动化和控制系统中。其高精度控制、广泛的适应性和高效电力管理使其成为工业自动化和控制系统中的重要组件。

###ABB 3BHE004573R0145 UFC760BE145 Input/Output Control Card

####Technical specifications

-* * Model * *: 3BHE004573R0145

-* * Backup model * *: UFC760BE145

-* * Manufacturer * *: ABB

-* * Series * *: UNITOL 6000

-Product Type: Phase Modulator

-* * Function * *: Link protection of DC bus circuit, built-in braking circuit, fault diagnosis and protection mechanism.

-Rated voltage: 3.3kV to 6.6kV (50/60Hz)

-Working voltage: 230V AC.

-Output frequency: 50Hz.

-Input current: 2.0A.

-Control accuracy: ± 0.1%.

-Communication protocols: MODBUS TCP/IP, PROFIBUS DP, Modbus TCP, IEC 61850.

-* * Control ｕｐｄａｔｅ time * *: 250 μ s.

-* * Power consumption * *: 24W @ 24V DC ± 15%.

-Operating temperature range: -25 ° C to+55 ° C.

-* * Size * *: 482.6 x 132.5 x 405 mm (19 "rack).

-Weight: 0.5kg.

-Protection level: IP20 (front panel), IP00 (interior).

-* * Certification * *: UL 508C, CE, cULus.

####Application Fields

-* * Power System * *: Used for high-voltage frequency converters and inverters to improve transmission efficiency and power quality.

-Industrial Automation: Suitable for variable frequency control of high-power equipment in the metallurgical, mining, and cement industries.

-Rail Transit: Supports stable operation of the traction system to ensure the reliability of the high-voltage auxiliary power supply system.

-In the field of new energy, it is suitable for wind and photovoltaic systems to optimize power output.

####Characteristics

-High precision control: Adopting advanced control algorithms to achieve a speed adjustment accuracy of ± 0.1%.

-Wide adaptability: Supports multiple voltage levels and is suitable for high-voltage inverters, wind energy, and photovoltaic systems.

-Efficient Power Management: By optimizing phase control and power quality, system efficiency is improved and energy losses are reduced.

-Enhanced connectivity: Supports multiple communication protocols and interface types for easy integration with other devices.

-Innovative thermal design: Using an aluminum nitride ceramic substrate, it can handle a continuous current of 150A at ambient temperatures up to 85 ° C.

####Precautions

-Installation environment: Ensure that the module is installed in a dust-free, dry, and well ventilated environment, avoiding high temperatures, high humidity, or corrosive gases.

-Electrical Connection: Connect power and signal lines correctly to avoid module damage or performance degradation caused by wiring errors.

ABB 3BHE004573R0145 UFC760BE145 is a high-performance phase modulator widely used in industrial automation and control systems. Its high-precision control, wide adaptability, and efficient power management make it an important component in industrial automation and control systems.
