ABB CI871AK01 通讯控制器

产品概述

ABB CI871AK01（订货号：3BSE092693R1）是一款高性能的工业通信接口模块，

专为 ABB 800xA DCS（分布式控制系统）和 AC 800M 控制系统设计。它作为控制器与外部设备（如变频器、远程 I/O 模块）之间的通信桥梁，实现高速数据交换。

技术规格

通信协议：支持 Modbus TCP/IP、PROFIBUS-DP（DP-V0/DP-V1）、PROFINET IO。

通信速率：最高 12 Mbps，支持自动波特率检测。

接口类型：

1 个 PROFIBUS D-sub 9 针接口。

RJ45 以太网接口（仅 CH1 通道有效），支持 V2.3/V2.4 标准。

安装方式：DIN 导轨或 800xA 专用机架。

电源：由底板供电。

工作温度范围：-25°C 至 +70°C。

防护等级：IP20。

尺寸：59 mm（宽）× 186 mm（高）× 127.5 mm（深）。

重量：0.7 kg。

功能特点

高速数据传输：支持 Modbus TCP/IP 协议，实现快速、稳定的数据交换，适用于对实时性要求高的工业场景。

多协议兼容：兼容多种工业标准协议，适用于不同的自动化环境。

远程管理：支持远程监测和诊断，提高系统运维效率。

灵活扩展：模块化设计，便于维护和升级，可扩展性强。

工业级可靠性：具备较强的抗干扰能力，适用于严苛的工业环境。

冗余电源设计：内置 DC/DC 转换器，确保供电稳定性。

集成操作系统：集成 NuttX 嵌入式操作系统，处理能力强大，适用于复杂算法与实时监控。

应用领域

过程控制：广泛应用于石油、化工、制药、冶金等行业的过程自动化。

电力系统：适用于发电厂、变电站等场景，实现远程监测和数据采集。

制造自动化：用于智能制造、工业机器人控制等，提高生产效率。

水处理系统：在污水处理、自来水厂等环境中，实现远程监测和数据通信。

ABB CI871AK01 Communication Controller

product overview

ABB CI871AK01 (order number: 3BSE092693R1) is a high-performance industrial communication interface module designed specifically for ABB 800xA DCS (distributed control system) and AC 800M control systems. It serves as a communication bridge between the controller and external devices such as frequency converters and remote I/O modules, enabling high-speed data exchange.

technical specifications

Communication protocol: Supports Modbus TCP/IP, PROFIBUS-DP (DP-V0/DP-V1), and PROFINET IO.

Communication speed: up to 12 Mbps, supports automatic baud rate detection.

Interface type:

1 PROFIBUS D-sub 9-pin interface.

RJ45 Ethernet interface (only valid for CH1 channel), supporting V2.3/V2.4 standards.

Installation method: DIN rail or 800xA dedicated rack.

Power supply: Powered by the motherboard.

Working temperature range: -25 ° C to+70 ° C.

Protection level: IP20.

Dimensions: 59 mm (width) x 186 mm (height) x 127.5 mm (depth).

Weight: 0.7 kg.

Functional Features

High speed data transmission: Supports Modbus TCP/IP protocol to achieve fast and stable data exchange, suitable for industrial scenarios with high real-time requirements.

Multi protocol compatibility: Compatible with multiple industrial standard protocols, suitable for different automation environments.

Remote management: supports remote monitoring and diagnosis to improve system operation and maintenance efficiency.

Flexible Expansion: Modular design, easy to maintain and upgrade, strong scalability.

Industrial grade reliability: With strong anti-interference ability, suitable for harsh industrial environments.

Redundant power supply design: Built in DC/DC converter to ensure power supply stability.

Integrated operating system: Integrated with NuttX embedded operating system, with powerful processing capabilities, suitable for complex algorithms and real-time monitoring.

application area

Process control: widely used in process automation in industries such as petroleum, chemical, pharmaceutical, metallurgy, etc.

Power system: suitable for scenarios such as power plants and substations, enabling remote monitoring and data collection.

Manufacturing automation: used for intelligent manufacturing, industrial robot control, etc., to improve production efficiency.

Water treatment system: It enables remote monitoring and data communication in environments such as sewage treatment and water treatment plants.
