ABB PM803F 3BDH000530R1 输入输出模块

主要特点

• 高性能处理器：配备 32 位 RISC 微处理器，主频高达 400 MHz，能够处理复杂的控制算法和任务。
• 紧凑设计：尺寸为 70 mm × 100 mm × 65 mm，适合空间有限的控制柜。
• 多种通信协议：支持 Modbus RTU、EtherNet/IP，以及 IEC 60870-5-101/104、DNP3、OPC UA 等。
• 灵活的 I/O 扩展：最大支持 256 个 I/O 点，可通过扩展模块增加数字和模拟输入输出。
• 高可靠性：工作温度范围 -25°C 至 70°C，适用于恶劣工业环境。
• 易于维护：DIN 导轨安装，支持远程诊断和故障检测。

技术规格

• 处理器：32 位 RISC 微处理器，主频 400 MHz。
• 内存：256 MB RAM，128 MB Flash。
• 供电电压：24V DC ±10%。
• 功耗：约 3W。
• 通信接口：1 个以太网口，1 个 RS485 口。
• I/O 容量：最大支持 256 个 I/O 点。
• 工作温度：-25°C 至 70°C。
• 存储温度：-40°C 至 85°C。
• 尺寸：70 mm × 100 mm × 65 mm。
• 重量：约 2Kg。

•

应用场景

• 工业自动化：用于控制和监控生产线上的各种设备。
• 电力系统：用于发电机组控制。
• 水处理：用于监测和控制水质。
• 食品和饮料加工：提升生产线的自动化水平和卫生安全。

ABB PM803F 3BDH000530R1 Input/Output Module

product overview

ABB PM803F 3BDH000530R1 is the core controller module of ABB AC800F series PLC, designed specifically for small and medium-sized automation systems. It has high-performance processing capabilities, flexible I/O expansion, and multiple communication interfaces, and is widely used in the field of industrial automation.

main features

High performance processor: equipped with a 32-bit RISC microprocessor, with a clock speed of up to 400 MHz, capable of processing complex control algorithms and tasks.

Compact design: with dimensions of 70 mm x 100 mm x 65 mm, suitable for control cabinets with limited space.

Multiple communication protocols: Supports Modbus RTU, EtherNet/IP, as well as IEC 60870-5-101/104, DNP3, OPC UA, etc.

Flexible I/O expansion: Supports up to 256 I/O points, and can increase digital and analog input/output through expansion modules.

High reliability: Operating temperature range of -25 ° C to 70 ° C, suitable for harsh industrial environments.

Easy to maintain: DIN rail installation, supports remote diagnosis and fault detection.

technical specifications

Processor: 32-bit RISC microprocessor with a main frequency of 400 MHz.

Memory: 256 MB RAM, 128 MB Flash.

Power supply voltage: 24V DC ± 10%.

Power consumption: approximately 3W.

Communication interface: 1 Ethernet port, 1 RS485 port.

I/O capacity: Supports a maximum of 256 I/O points.

Working temperature: -25 ° C to 70 ° C.

Storage temperature: -40 ° C to 85 ° C.

Dimensions: 70 mm x 100 mm x 65 mm.

Weight: Approximately 200g.

Application scenarios

Industrial automation: used to control and monitor various equipment on the production line.

Power system: used for controlling generator sets.

Water treatment: used for monitoring and controlling water quality.

Food and beverage processing: Improve the automation level and hygiene safety of production lines.

ABB PM803F 3BDH000530R1 is an ideal controller module in the field of industrial automation due to its high performance, compact design, support for multiple communication protocols, and high reliability.
