ABB 216GW61 电源控制模块

产品概述

ABB 216GW61 是一款高性能的输入变换器模块，专为 ABB S800 I/O 系统设计。它能够将模拟量信号进行隔离和变换，适用于多种工业自动化和电力系统应用。

技术规格

主要特点和优势

• 高精度信号采集：配合 16 位高精度 ADC 转换器，有效抑制高频干扰和信号噪声，确保测量精度达到 ±0.1% FS。
• 抗干扰设计：内置光电隔离技术和冗余电源设计，可在强电磁干扰环境下稳定工作。
• 灵活配置：支持热插拔功能，可在系统运行状态下进行维护更换，显著降低停机时间。
• 宽温适应性：能够在 -20°C 至 +60°C 的宽温范围内稳定运行。
• 系统集成能力：通过 B448C 并行总线与保护处理单元（如 216VC62a）通信，兼容 HART 协议。

应用领域

• 电力系统：用于发电厂、变电站的设备监控和保护。
• 石油化工：监测和控制生产过程中的关键参数。
• 制造业：在自动化生产线中，用于实时采集生产数据。
• 水处理：用于污水处理厂和净水厂的自动化管理。

相关产品

• ABB 216EA61b：模拟量输入模块，与 216GW61 配合使用，实现高精度模拟信号采集。
• ABB 216VC62a：保护处理单元，通过 B448C 总线与 216GW61 通信，实现对发电机、变压器的全面保护。
• ABB 216AB61：数字量输出模块，提供 32 路数字输出通道。
• ABB 216PS61：电源模块，为 S800 I/O 系统提供冗余电源。

ABB 216GW61 power control module

product overview

ABB 216GW61 is a high-performance input converter module designed specifically for ABB S800 I/O systems. It can isolate and transform analog signals, suitable for various industrial automation and power system applications.

technical specifications

Parameter specifications

12 input channels for current/voltage input

Input signal type: current (e.g. 4-20mA), voltage (e.g. 0-10V)

Isolation characteristics: Channel isolation, isolation voltage 500V AC

Working temperature range -20 ° C to+60 ° C

Protection level IP20

Modular design for installation, supporting hot swapping

Main features and advantages

High precision signal acquisition: Combined with a 16 bit high-precision ADC converter, it effectively suppresses high-frequency interference and signal noise, ensuring measurement accuracy of ± 0.1% FS.

Anti interference design: Equipped with built-in optoelectronic isolation technology and redundant power supply design, it can work stably in strong electromagnetic interference environments.

Flexible configuration: Supports hot swapping function, can be maintained and replaced while the system is running, significantly reducing downtime.

Wide temperature adaptability: able to operate stably within a wide temperature range of -20 ° C to+60 ° C.

System integration capability: Communicate with protection processing units (such as 216VC624) through B448C parallel bus, compatible with HART protocol.

application area

ABB 216GW61 is widely used in the following fields:

Power system: used for equipment monitoring and protection in power plants and substations.

Petrochemical industry: monitoring and controlling key parameters in the production process.

Manufacturing industry: used for real-time collection of production data in automated production lines.

Water treatment: used for automated management of sewage treatment plants and water purification plants.

Related products

ABB 216EA61b: Analog input module, used in conjunction with 216GW61 to achieve high-precision analog signal acquisition.

ABB 216VC624: Protection processing unit, communicates with 216GW61 through B448C bus to achieve comprehensive protection of generators and transformers.

ABB 216AB61: Digital output module, providing 32 digital output channels.

ABB 216PS61: Power module, providing redundant power supply for S800 I/O system.
