ABB PFEA113-20 张力控制器

产品概述

ABB PFEA113-20 是一款高性能的张力控制器，专为工业自动化和过程控制系统设计。

它能够精确测量和控制卷材或连续材料在生产和加工过程中的张力，确保产品质量和生产效率。

技术规格

• 供电方式：24V DC。
• 输入信号：4-20mA 或模拟信号。
• 输出信号：继电器、模拟量（如 4-20mA）或数字量。
• 测量范围：0-20 bar 或 0-10 kN。
• 精度：±0.1% 满量程。
• 响应时间：小于 10ms。
• 工作温度范围：-10°C 至 55°C 或 -20°C 至 60°C。
• 防护等级：IP20。
• 尺寸：225 mm × 160 mm × 80 mm。
• 重量：2.5kg。

主要特点和优势

• 高精度测量：采用高精度传感器，确保张力测量的准确性和可靠性。
• 快速响应：控制回路响应迅速，能够快速调整张力。
• 多功能集成：支持多种控制模式和通信接口，适应不同工艺需求。
• 模块化设计：便于安装和扩展，适合复杂工业系统。
• 高可靠性：抗干扰能力强，维护周期长。
• 易于集成：设计紧凑，易于安装和维护，适合多种工业环境。

应用领域

• 包装行业：用于控制包装材料的张力，确保包装过程的稳定性和一致性。
• 印刷行业：用于控制印刷材料的张力，避免材料断裂和褶皱。
• 纺织行业：用于控制纱线或织物的张力，确保生产的质量和一致性。
• 造纸行业：用于纸张生产过程中的张力控制。
• 金属加工：用于金属加工过程中的张力控制。
• 塑料薄膜行业：用于薄膜生产和加工过程中的张力控制。
• 电缆制造：用于电线或电缆在拉伸和卷绕过程中的张力控制。

ABB PFEA113-20 Tension Controller

product overview

ABB PFEA113-20 is a high-performance tension controller designed specifically for industrial automation and process control systems.

It can accurately measure and control the tension of coils or continuous materials during production and processing, ensuring product quality and production efficiency.

technical specifications

Power supply mode: 24V DC.

Input signal: 4-20mA or analog signal.

Output signal: relay, analog quantity (such as 4-20mA) or digital quantity.

Measurement range: 0-20 bar or 0-10 kN.

Accuracy: ± 0.1% of full scale.

Response time: less than 10ms.

Working temperature range: -10 ° C to 55 ° C or -20 ° C to 60 ° C.

Protection level: IP20.

Dimensions: 225 mm x 160 mm x 80 mm.

Weight: 2.5kg.

Main features and advantages

High precision measurement: Using high-precision sensors to ensure the accuracy and reliability of tension measurement.

Quick response: The control circuit responds quickly and can adjust tension quickly.

Multi functional integration: supports multiple control modes and communication interfaces to meet different process requirements.

Modular design: easy to install and expand, suitable for complex industrial systems.

High reliability: Strong anti-interference ability and long maintenance cycle.

Easy to integrate: Compact design, easy to install and maintain, suitable for various industrial environments.

application area

ABB PFEA113-20 is widely used in the following fields:

Packaging industry: used to control the tension of packaging materials, ensuring the stability and consistency of the packaging process.

Printing industry: used to control the tension of printing materials, avoiding material breakage and wrinkles.

Textile industry: used to control the tension of yarn or fabric, ensuring the quality and consistency of production.

Paper industry: used for tension control in the paper production process.

Metal processing: used for tension control during metal processing.

Plastic film industry: used for tension control in film production and processing.

Cable manufacturing: used for tension control of wires or cables during stretching and winding processes.
