Bentley 3500/15 133292-01 低压直流电源模块

Bentley 3500/15 133292-01 低压直流电源模块是 Bently Nevada 3500 系列机械状态监测系统的重要组成部分，

专为工业环境中旋转机械的状态监测系统提供稳定的低压直流电源。该模块采用高效的 DC-DC 变换技术，

确保电源转换的高效率和稳定性。

紧凑设计：半高模块设计，节省机架空间，便于集成。

重量 约 1.39 kg

其他工业领域：适用于所有需要对关键机械进行状态监测的行业。

Bentley 3500/15 133292-01 Low Voltage DC Power Supply Module

Product Overview:

The Bentley 3500/15 133292-01 low-voltage DC power module is an important component of the Bently Nevada 3500 series mechanical condition monitoring system,

Specially designed to provide stable low-voltage DC power supply for the condition monitoring system of rotating machinery in industrial environments. This module adopts efficient DC-DC conversion technology,

Ensure high efficiency and stability of power conversion.

Main features and advantages

Efficient and Stable: Adopting efficient DC-DC conversion technology to ensure high efficiency and stability of power conversion, reducing energy loss.

Multiple protection functions: It has multiple protection functions such as overcurrent, overvoltage, and short circuit, and can quickly cut off the power or adjust the output in case of abnormal situations, protecting the system from damage.

Electromagnetic interference protection: Carefully designed circuit board and housing structure effectively prevent electromagnetic interference, ensuring the purity and stability of power output.

Redundancy design: Supports single or dual power redundancy configuration. When two power modules are installed, the backup power supply can seamlessly switch in case of main power failure, ensuring the continuous operation of the system.

Wide input voltage range: The input voltage range is 20 to 30 VDC, suitable for various low-voltage DC power sources.

Hot swappable capability: Under redundant configuration, power modules can be replaced without interrupting system operation.

Compact design: Half height module design saves rack space and facilitates integration.

technical specifications

Product model Bentley 3500/15 133292-01

Manufacturer Bentley Nevada (Baker Hughes)

Input voltage range of 20 to 30 VDC

Convert the output voltage to the stable voltage required by the 3500 system (usually+24 VDC)

The output current can reach 10.0 A

Installation method: ｉｎｓｅｒｔ into the dedicated power slot on the left side of the 3500 rack

Working temperature range -30 ° C to+65 ° C

Storage temperature range -40 ° C to+85 ° C

Relative humidity 95%, non condensing

Dimensions (height x width x depth) approximately 120.7 mm x 50.8 mm x 251.5 mm

Weight approximately 1.39 kg

application area

Bentley 3500/15 133292-01 low-voltage DC power module is widely used in the following industrial fields:

Oil and natural gas: used for monitoring drilling equipment, pump stations, compressors, etc.

Power generation: used for monitoring and protecting equipment such as generators and turbines.

Chemical industry: used to monitor key equipment and ensure smooth production processes.

Pulp and paper: used for monitoring various types of rotating machinery.

Water treatment: used for monitoring equipment such as water pumps and fans.

Other industrial fields: applicable to all industries that require condition monitoring of critical machinery.

Related products

Low voltage DC power input module (PIM): model 133300-01, used in conjunction with power modules.

AC power module: used to provide AC power support.

High voltage DC power module: used to provide high voltage DC power.

3500 series monitoring modules: such as vibration monitoring module, temperature monitoring module, etc.

3500 series rack: used for installing 3500 series modules.

These modules, together with the Bentley 3500/15 133292-01 low-voltage DC power module, form a complete mechanical condition monitoring system.
