Product Information

Brand: Bently Nevada

Model: 330800-16-00-039-03-02

Type: Vibration Sensor (Eddy Current Displacement Sensor)

Application System: Mainly used for vibration monitoring of rotating machinery such as steam turbines and compressors, it is a core component of the Bently Nevada 3300 series monitoring system.

core parameters

Measurement range: 0-250 μ m (peak to peak)

Sensitivity: 8V/mm (typical value)

Frequency response: 0-10kHz (suitable for high-frequency vibration monitoring)

Working temperature: -40 ℃ to+85 ℃ (suitable for harsh industrial environments)

Output signal: voltage signal (proportional to vibration displacement)

Power supply requirements: A preamplifier (such as 330180 series) is required to provide a -24V DC power supply.

Specification characteristics

Probe diameter: 8mm (standard size, suitable for most installation scenarios)

Probe length: 50mm (can be customized according to actual needs)

Cable type: coaxial cable (usually 5 or 9 meters in length, needs to be matched with a preamplifier interface)

Protection level: IP65 (dustproof and waterproof, suitable for industrial sites)

Material: The probe housing is made of stainless steel, and the cable is designed with low noise coaxial.

Usage scenarios

Turbine vibration monitoring:

Monitor the axial vibration of the turbine rotor to prevent faults such as bearing wear and rotor imbalance.

Typical applications: power plant steam turbines, gas turbines.

Compressor status monitoring:

Detect the vibration of the compressor rotor to avoid seal failure or mechanical damage caused by excessive vibration.

Typical application: Centrifugal compressors in the petrochemical industry.

Fan and pump equipment:

Monitor the vibration of the fan impeller and pump shaft to ensure stable operation of the equipment.

Key mechanical protection:

As an input for mechanical protection systems (such as Bently 3500 series), it triggers an alarm or shutdown signal.

Dimensions and Weight

Probe size: diameter 8mm x length 50mm (excluding cable)

Probe weight: approximately 50g (excluding cables)

Cable weight: approximately 50g/meter (taking standard coaxial cable as an example)

Pre processor size (for use with): approximately 100mm x 80mm x 30mm (length x width x height)

Weight of the preamplifier: approximately 200g.

Related models and compatibility

Model of preamplifier:

330180-50-00 (standard type, suitable for most 3300 series probes)

330180-91-00 (High temperature type, suitable for scenarios where the working temperature of the probe is>120 ℃)

Extension cable model:

330130-040-00 (5-meter coaxial cable)

330130-080-00 (9-meter coaxial cable)

Monitoring module:

3300/16 (dual channel vibration monitoring module, supporting 330800 series probes)

3500/42M (four channel vibration monitoring module, compatible with 3300 series probes)

Alternative models:

330800-16-00-050-03-02 (measurement range 0-500 μ m, other parameters are the same)

330800-16-00-010-03-02 (measurement range 0-100 μ m, suitable for low amplitude scenarios).
