EMERSON KJ3243X1-BB2 输入输出模块

EMERSON KJ3243X1-BB2 是一款高性能的 Profibus DP 接口卡，属于 DeltaV 系列中的 Series 2 Plus。

该模块专为工业自动化和过程控制系统设计，能够实现高效的数据传输和可靠的通信。

安装要求：在移除或插入设备之前，必须切断现场电源。

多种通信协议支持：支持多种工业标准协议，如 Profibus DP。

KJ3243X1-BB2 广泛应用于需要快速、可靠数据交换的自动化控制系统中。它特别适用于 DeltaV 系统，能够确保与 Profibus DP 现场设备之间的可靠连接，从而提高操作效率和可靠性。此外，该模块还符合 3G Ex ec IIC Gc 标准，并获得了 FM19ATEX0173U、IECEx FMG 19.0019U 和 FM21UKEX0017U 等认证，使其适用于危险环境。

EMERSON KJ3243X1-BB2 Input/Output Module

Product Overview

EMERSON KJ3243X1-BB2 is a high-performance Profibus DP interface card, belonging to the Series 2 Plus of the DeltaV series.

This module is designed specifically for industrial automation and process control systems, enabling efficient data transmission and reliable communication.

technical specifications

Working voltage: 12V DC.

Current: 600mA.

Working temperature range: -40 ° C to+70 ° C.

Environmental impact: able to withstand 10g/2 Sineway impact.

Vibration: 1mm peak to peak vibration, frequency range from 2 to 13.2Hz; 0.7g from 13.2 to 150Hz.

Relative humidity: 5% to 95%, non condensing state.

Protection level: ISA-S71.04 Class G3.

Installation requirement: Before removing or inserting equipment, the on-site power must be cut off.

Functional Features

High reliability: The use of a rotary key system ensures compatibility between the I/O card and the terminal block, and the terminal block needs to be set with corresponding key positions for the I/O card being used.

High precision: The module design emphasizes precision and is suitable for industrial automation applications that require precise control.

Redundancy design: It has redundancy design to ensure that it cannot be removed or inserted when the system is powered on, enhancing the stability of the system.

No need for calibration: There are no user service parts inside the device, so calibration is not required. It is not recommended to disassemble it by oneself, which simplifies maintenance work.

Multiple communication protocol support: Supports multiple industrial standard protocols, such as Profibus DP.

application area

KJ3243X1-BB2 is widely used in automation control systems that require fast and reliable data exchange. It is particularly suitable for DeltaV systems, ensuring reliable connections with Profibus DP field devices, thereby improving operational efficiency and reliability. In addition, the module also complies with the 3G Ex ec IIC Gc standard and has obtained certifications such as FM19ATEX0173U, IECEx FMG 19.0019U, and FM21UKEX0017U, making it suitable for hazardous environments.
