### GE DS2020DACAG2 信号调节电路板模块

#### 技术规格

- **型号**：DS2020DACAG2

- **制造商**：通用电气（GE）

- **系列**：EX2100 励磁控制

- **输入电压**：115VAC 或 230VAC

- **输出电压**：125VDC

- **输出功率**：约1000瓦

- **最大输出电流**：9.5A

- **工作温度范围**：-40°C至85°C

- **湿度**：5%至95%，非冷凝

- **通信接口**：以太网和RS-485

- **尺寸**：6.81英寸（173毫米）高 × 4.06英寸（103毫米）宽 × 1.18英寸（30毫米）深

- **重量**：1.06磅（0.48公斤）

#### 功能特点

- **高效电源转换**：将交流电源转换为直流电源，确保工业操作的连续性和优化。

- **兼容性**：兼容各种工业系统，适用于广泛的工业应用。

- **冗余设计**：支持冗余配置，提高系统的可靠性和可用性。

- **模块化设计**：便于安装和更换。

- **信号抗干扰**：具有强大的信号抗干扰特性。

- **操作界面**：可能配备防水面板，面板矩阵式显示128×64像素，四行汉化字体。

- **存储功能**：具有2GB MicroSD存储卡，可存储十年工作内容、程序和安全事件等。

#### 应用场景

- **工业控制系统**：如GE Speedtronic Mark V 涡轮机控制系统。

- **励磁控制器**：提供可靠的电源转换，确保系统的稳定运行。

- **能源管理系统**：在完全失去控制电源时，提供额外的本地能源存储以延长运行时间。

- **发电应用**：包括燃煤电厂、燃气电厂、核电厂和可再生能源发电厂。

#### 注意事项

- **安装环境**：确保模块安装在无尘、干燥且通风良好的环境中，避免高温、高湿或腐蚀性气体。

- **电气连接**：正确连接电源和信号线，避免接线错误导致的模块损坏或性能下降。

DS2020DACAG2模块是GE Mark V系列控制系统的重要组成部分，广泛应用于工业自动化和发电领域。其高性能、多功能和高可靠性使其成为工业控制系统中的重要组件。

###GE DS2020DACAG2 Signal Conditioning Circuit Board Module

####Technical specifications

-* * Model * *: DS2020DACAG2

-* * Manufacturer * *: General Electric (GE)

-* * Series * *: EX2100 Excitation Control

-* * Input voltage * *: 115VAC or 230VAC

-Output voltage: 125VDC

-* * Output power * *: Approximately 1000 watts

-Maximum output current: 9.5A

-* * Operating temperature range * *: -40 ° C to 85 ° C

-Humidity: 5% to 95%, non condensing

-* * Communication interface * *: Ethernet and RS-485

-* * Size * *: 6.81 inches (173 millimeters) high x 4.06 inches (103 millimeters) wide x 1.18 inches (30 millimeters) deep

-Weight: 1.06 pounds (0.48 kilograms)

####Functional Features

-Efficient power conversion: Convert AC power to DC power to ensure continuity and optimization of industrial operations.

-Compatibility: Compatible with various industrial systems and suitable for a wide range of industrial applications.

-* * Redundant design * *: Supports redundant configuration to improve system reliability and availability.

-Modular design: easy to install and ｒｅｐｌａｃｅ.

-* * Signal anti-interference * *: It has strong signal anti-interference characteristics.

-* * Operating interface * *: may be equipped with a waterproof panel, with a matrix display of 128 × 64 pixels and four lines of Chinese font.

-* * Storage Function * *: Equipped with a 2GB MicroSD memory card, it can store work content, programs, and security events for ten years.

####Application scenarios

-Industrial control systems, such as the GE Speedtronic Mark V turbine control system.

-Excitation controller: Provides reliable power conversion to ensure stable operation of the system.

-Energy Management System: Provides additional local energy storage to extend operating time in the event of complete loss of control over power.

-* * Power generation applications * *: including coal-fired power plants, gas-fired power plants, nuclear power plants, and renewable energy power plants.

####Precautions

-Installation environment: Ensure that the module is installed in a dust-free, dry, and well ventilated environment, avoiding high temperatures, high humidity, or corrosive gases.

-Electrical Connection: Connect power and signal lines correctly to avoid module damage or performance degradation caused by wiring errors.

The DS2020DACAG2 module is an important component of the GE Mark V series control system, widely used in industrial automation and power generation fields. Its high performance, versatility, and high reliability make it an important component in industrial control systems.
