GE IS220PRTDH1B 输入模块

产品概述

GE IS220PRTDH1B 是一款高性能的电阻温度检测器（RTD）输入模块，专为工业自动化和过程控制系统设计。它能够将来自 RTD 传感器的电阻信号转换为数字信号，以便控制系统进行温度测量和控制。

技术规格

• 输入通道：8 个独立的输入通道。
• 支持的 RTD 类型：如 PT100 或 PT1000。
• 测量范围：可覆盖较宽的温度测量范围。
• 输出信号：数字信号，支持 4-20mA 或 0-10V 的输入信号。
• 工作温度：-10℃ 至 +55℃。
• 防护等级：IP52（可选 IP65）。
• 安装方式：嵌入式安装。
• 电源：AC 85-270V，频率 50/60Hz±5%。
• 功耗：<1W。
• 尺寸：34 x 18 x 10 cm。
• 重量：约 4.40 磅。
• 认证：CE、UL。

主要特点和优势

• 高精度测量：能够精确测量温度，适用于需要高精度温度控制的工业应用。
• 多种 RTD 支持：支持多种类型的 RTD 传感器，如 PT100 和 PT1000。
• 易于集成：与 GE Mark VIe Speedtronic 系统无缝集成，适用于燃气轮机和蒸汽轮机的控制系统。
• 诊断功能：提供诊断信息，支持维护和故障排查。
• 高可靠性：适用于恶劣工业环境，确保长期稳定运行。

应用领域

• 工业自动化：用于工厂自动化、过程控制等领域，连接 PLC、传感器、执行器、HMI 等工业设备。
• 燃气轮机控制系统：用于监测和控制燃气轮机的运行。
• 蒸汽轮机控制系统：同样适用于蒸汽轮机的控制系统。
• 温度敏感的工业过程控制：如化工、制药、食品加工等行业。
• 能源管理和楼宇自动化：用于能源管理和楼宇自动化系统。

GE IS220PRTDH1B Input Module

product overview

GE IS220PRTDH1B is a high-performance resistance temperature detector (RTD) input module designed specifically for industrial automation and process control systems. It can convert resistance signals from RTD sensors into digital signals for temperature measurement and control in the control system.

technical specifications

Input channels: 8 independent input channels.

Supported RTD types: such as PT100 or PT1000.

Measurement range: It can cover a wide temperature measurement range.

Output signal: digital signal, supporting 4-20mA or 0-10V input signals.

Working temperature: -10 ℃ to+55 ℃.

Protection level: IP52 (optional IP65).

Installation method: Embedded installation.

Power supply: AC 85-270V, frequency 50/60Hz ± 5%.

Power consumption:<1W.

Size: 34 x 18 x 10 cm.

Weight: Approximately 4.40 pounds.

Certification: CE, UL.

Main features and advantages

High precision measurement: capable of accurately measuring temperature, suitable for industrial applications that require high-precision temperature control.

Multiple RTD support: Supports multiple types of RTD sensors, such as PT100 and PT1000.

Easy to integrate: seamlessly integrated with GE Mark VIe Speedtronic system, suitable for control systems of gas turbines and steam turbines.

Diagnostic function: Provides diagnostic information, supports maintenance and troubleshooting.

High reliability: Suitable for harsh industrial environments, ensuring long-term stable operation.

application area

GE IS220PRTDH1B is widely used in the following fields:

Industrial automation: used in fields such as factory automation and process control, connecting industrial equipment such as PLCs, sensors, actuators, and HMIs.

Gas turbine control system: used to monitor and control the operation of gas turbines.

Steam turbine control system: also applicable to the control system of steam turbines.

Temperature sensitive industrial process control: industries such as chemical, pharmaceutical, and food processing.

Energy Management and Building Automation: Used for energy management and building automation systems.
