GE IS220PSCAH1B Communication Module

product overview

GE IS220PSCAH1B is a high-performance serial communication I/O pack designed specifically for GE Mark VIe systems. It provides an interface between the serial communication terminal board and up to two I/O Ethernet networks.

technical specifications

Port configuration:

2 Ethernet ports, supporting Ethernet Modbus master protocol, suitable for simplex network configuration.

Single three pin power input.

The output is transmitted through the DC-62 pin connector via the terminal board.

Network function:

Supports Ethernet Modbus master protocol and can connect up to 18 Ethernet Modbus stations.

Alarm function:

Including communication port # node # communication failure - no response.

Communication Port # Node # Communication - Data Error.

Configure problem port #.

Electric drive port # failed to save command.

Main features and advantages

High reliability: Supports redundant dual power input to improve equipment reliability and stability.

Multiple network configurations: Suitable for multiple network configurations, including redundant controller configurations for dual, simplex, or TMR controllers.

Easy to install and configure: Supports parallel or vertical installation options, and can be flexibly configured according to actual needs.

Powerful network functionality: supports multiple network protocols, has automatic negotiation function, and can automatically detect network devices and link status.

High precision signal processing: capable of accurately processing analog signals to ensure data accuracy and real-time performance.

application area

GE IS220PSCAH1B is widely used in the following fields:

Industrial automation: used in fields such as factory automation and process control, connecting industrial equipment such as PLCs, sensors, actuators, and HMIs.

Power industry: applied to power plants, substations, etc., to build reliable industrial communication networks.

Gas turbine control system: As a key component of the Mark VIe system IONet network, it is used to connect control modules, I/O modules, and monitoring systems.

Steam turbine control system: also applicable to Mark VIeS safety control system, providing reliable industrial Ethernet connection
