Honeywell CC-PDIS01 多功能数字量输入模块

产品概述

Honeywell CC-PDIS01 是一款高性能的多功能数字量输入模块，专为工业自动化和控制系统设计。它能够接收和处理来自现场设备的数字信号，如开关状态、传感器读数等，并将其转换为控制系统能够识别的标准数字信号。

技术规格

输入通道数：32通道。

输入信号类型：24V DC 和 100V AC。

工作电压：24V DC。

工作温度范围：-40°C至+70°C。

通信接口：支持Modbus RTU协议。

防护等级：IP65。

安装方式：面板安装。

尺寸：未明确提供具体尺寸，但模块设计紧凑，便于安装。

重量：约2公斤。

功能特点

高精度信号处理：能够精确采集和处理数字信号，确保信号的准确性和可靠性。

支持事件序列记录：模块可以记录数字输入的状态变化，并按照时间顺序记录下来，方便用户对系统事件进行分析和追溯。

灵活配置：支持多种通信协议，如Modbus、Profibus等，便于与其他控制系统和设备进行高效的数据交换和通信。

多种操作模式：

正常模式：20ms PV扫描。

事件序列模式：1ms分辨率SOE，20ms PV扫描。

低延迟模式：5ms PV扫描。

内部诊断：具备广泛的内部诊断功能，确保数据完整性。

开路检测：仅限正常模式。

冗余选项：支持冗余配置，提高系统可靠性。

内部或外部现场电源选择：提供非易燃现场电源。

正向/反向输入指示。

电流隔离：确保信号传输的稳定性。

应用领域

工业自动化：用于需要高精度控制和监控的工业环境。

过程控制：在化工、能源、水处理等行业中，用于监测和控制过程参数。

安全系统：用于安全相关的监控和报警系统。

注意事项

安装环境：确保模块安装在无尘、干燥且通风良好的环境中，避免高温、高湿或腐蚀性气体。

电气连接：正确连接电源和信号线，避免接线错误导致的模块损坏或性能下降。

Honeywell CC-PDIS01 多功能数字量输入模块凭借其高性能、多功能和高可靠性，成为工业自动化和控制系统中的重要组件。

Honeywell CC-PBIS01 Multi functional Digital Input Module

product overview

Honeywell CC-PDIS01 is a high-performance multifunctional digital input module designed specifically for industrial automation and control systems. It can receive and process digital signals from on-site devices, such as switch status, sensor readings, etc., and convert them into standard digital signals that the control system can recognize.

technical specifications

Number of input channels: 32 channels.

Input signal types: 24V DC and 100V AC.

Working voltage: 24V DC.

Working temperature range: -40 ° C to+70 ° C.

Communication interface: Supports Modbus RTU protocol.

Protection level: IP65.

Installation method: Panel installation.

Size: The specific size is not provided, but the module design is compact and easy to install.

Weight: Approximately 2 kilograms.

Functional Features

High precision signal processing: capable of accurately collecting and processing digital signals, ensuring the accuracy and reliability of the signals.

Support event sequence recording: The module can record the status changes of digital inputs and record them in chronological order, making it convenient for users to analyze and trace system events.

Flexible configuration: Supports multiple communication protocols such as Modbus, Profibus, etc., facilitating efficient data exchange and communication with other control systems and devices.

Multiple operating modes:

Normal mode: 20ms PV scan.

Event sequence mode: 1ms resolution SOE, 20ms PV scan.

Low latency mode: 5ms PV scan.

Internal diagnosis: It has a wide range of internal diagnostic functions to ensure data integrity.

Open circuit detection: limited to normal mode only.

Redundancy option: Supports redundant configuration to improve system reliability.

Internal or external on-site power supply selection: Provide non flammable on-site power supply.

Forward/reverse input indication.

Current isolation: Ensure the stability of signal transmission.

application area

Industrial automation: used in industrial environments that require high-precision control and monitoring.

Process control: Used in industries such as chemical, energy, and water treatment to monitor and control process parameters.

Security system: used for security related monitoring and alarm systems.

precautions

Installation environment: Ensure that the module is installed in a dust-free, dry, and well ventilated environment, avoiding high temperatures, high humidity, or corrosive gases.

Electrical connection: Connect power and signal lines correctly to avoid module damage or performance degradation caused by wiring errors.

The Honeywell CC-PBIS01 multifunctional digital input module has become an important component in industrial automation and control systems due to its high performance, versatility, and reliability.
