WOODWARD 8200-1302 工业数字调速器

产品概述

Woodward 8200-1302 是一款高性能的数字调速器，属于 Woodward 505D 系列，专为工业和能源领域的精密控制应用设计。它广泛应用于发电、石油和天然气、水处理、造纸、钢铁和采矿等行业。

技术规格

输入电压范围：18-36V DC 或 24V DC。

工作温度范围：-22°F 至 158°F（-30°C 至 70°C）。

存储温度范围：-40°C 至 +125°C。

显示屏：8.4 英寸液晶显示器。

外壳类型：IACS UR E10（商用船用），具有 ATEX、IP-54 和污染等级 3 认证。

通信接口：支持 Modbus RTU、CAN、Ethernet 等协议。

模拟输入：8 个通道，可配置为 27 种功能中的任何一个。

输出：两个 4-20 mA 控制输出和八个 Form-C 继电器触点输出。

冗余设计：两个冗余速度输入，可接受磁性拾取装置、涡流探头或接近探头。

控制模式：提供配置模式、操作模式和校准模式。

防护等级：IP54。

功能特点

高精度控制：速度精度 ±0.05%，响应时间 <1 秒。

多种控制模式：包括速度控制、功率控制、负载控制等。

完善的保护功能：过速、欠速、过载和欠载保护。

灵活的配置：支持 PID 控制算法，可定制逻辑控制。

智能通信能力：支持多种通信协议，便于与其他设备集成。

自诊断功能：能够检测设备问题并提供相关信息，便于维护和修复。

应用领域

发电行业：控制发电机、汽轮机、燃气轮机等设备的转速。

石油和天然气：控制压缩机、泵站等设备的转速。

化工行业：控制反应釜转速。

造纸行业：控制纸机驱动。

船舶行业：控制推进系统。

其他工业应用：如自动化设备、能源管理和 HVAC 系统。

前面板设计

紧急跳闸键：用于紧急停机。

导航十字键：用于操作和调整。

软键命令：用于执行特定操作。

LED 指示灯：显示控制和硬件状态信息。

优势

模块化设计：易于扩展和维护。

高可靠性：采用冗余设计，确保系统稳定运行。

智能化：支持多种通信协议和远程监控功能。

Woodward 8200-1302 industrial digital governor

Product overview

Woodward 8200-1302 is a high-performance digital governor, belonging to Woodward 505d series, designed for precision control applications in the industrial and energy fields. It is widely used in power generation, oil and gas, water treatment, paper making, steel and mining industries.

technical specifications

Input voltage range: 18-36V DC or 24V DC.

Operating temperature range: -22 ° f to 158 ° f (-30 ° C to 70 ° C).

Storage temperature range: -40 ° C to+125 ° C.

Display: 8.4 inch LCD.

Enclosure type: IACS ur E10 (commercial marine), with ATEX, ip-54 and pollution level 3 certification.

Communication interface: support Modbus RTU, can, Ethernet and other protocols.

Analog input: 8 channels, which can be configured as any of 27 functions.

Outputs: two 4-20 ma control outputs and eight Form-C relay contact outputs.

Redundant design: two redundant speed inputs, which can accept magnetic pickup device, eddy current probe or proximity probe.

Control mode: configuration mode, operation mode and calibration mode are provided.

Protection grade: IP54.

Functional features

High precision control: speed accuracy ± 0.05%, response time<1 second.

Various control modes: including speed control, power control, load control, etc.

Perfect protection function: over speed, under speed, overload and under load protection.

Flexible configuration: it supports PID control algorithm and can customize logic control.

Intelligent communication capability: support a variety of communication protocols to facilitate integration with other devices.

Self diagnosis function: it can detect equipment problems and provide relevant information for maintenance and repair.

application area

Power generation industry: control the speed of generators, steam turbines, gas turbines and other equipment.

Oil and natural gas: control the speed of compressor, pump station and other equipment.

Chemical industry: control the speed of reaction kettle.

Paper industry: control paper machine drive.

Shipbuilding Industry: control propulsion system.

Other industrial applications: such as automation equipment, energy management and HVAC systems.

Front panel design

Emergency trip key: used for emergency shutdown.

Navigation cross key: used for operation and adjustment.

Soft key commands: used to perform specific operations.

LED indicator: display control and hardware status information.

advantage

Modular design: easy to expand and maintain.

High reliability: redundancy design is adopted to ensure the stable operation of the system.

Intelligentization: support a variety of communication protocols and remote monitoring functions.
